The Power T3S1-19 superwoofer has a whopping 19-inches of effective radiating cone area for deep bass and features a single 1-Ohm voice coil for easy wiring. This is the largest, most powerful loudspeaker Rockford Fosgate has ever built!
The Power T3S1-19 can rightfully be classified as a superwoofer due to its whopping 19-inches of effective radiating cone area! That’s right… we don’t need no stinkin’ 18″ subs … this is for genuine Car Audio Fanatics that want to go BIG like Mannie Fresh. We’re talkin’ Real Big bass and Real Big power handling in a Real Big ride.
The Power T3 19″ subwoofer incorporates technologies never before seen in car audio, like the Injection Molded Foam Surround, making the foam strong and durable like a rubberized material. The Edge Wound voice coil allows the windings to be very close with no air gaps so it stays cool for high power handling capacity. We also engineered a very efficient “Push/Pull” voice coil design with a huge Neodymium magnet for a very efficient motor assembly. Looking for more options? Check out all of our best subwoofers here.
FEATURES AT A GLANCE
- Aluminum dustcap
- Injection molded foam surround with VAST™
- Dual Nomex progressive spiders with stitched tinsel leads
- Three layer glass fiber/Aramid honeycomb/Glass fiber cone
- Proprietary surround mechanical clamping ring
- Diecast aluminum frame with integrated heat sink fins and venting
- Custom push spring insulated 4 AWG terminals
- Single layer edge wound aluminum 5″ voice coil
- Integrated die cast aluminum trim ring
- Dual gap multi-pole Neodymium push/pull motor structure
- Since voice coil design with dual (push/pull) windings
- 1 Year Warranty
Specification | Value |
---|---|
Magnet Weight | 115 oz. (3.26 Kg) |
Subwoofer Type | Superwoofer |
Voice Coil Type | Single Voice Coil |
Speaker Connector | 4 AWG Compression Terminal |
Power Handling (Watts RMS) | 3000 Watts RMS – 6000 Watts Max |
Nominal Impedance | 1-Ohm |
Size | 19″ |
CEA-2031 Compliant | CEA-2031 Guidelines |
Fs (Hz) | 27 |
Voice Coil Diameter | 5.0″ (127 mm) |
Qts | 0.32 |
Le (mH) | 0.45 |
Re (Ohms) | 0.8 |
Qms | 1.93 |
SPL (dB @ 1w/1m) | 91 |
Sd (cm²) | 1472 |
Vas (Liters) | 104.9 |
Qes | 0.38 |
Cutout Diameter | 17.72 in. (440 mm) |
Xmax (mm) | 34 |
Mounting Depth | 15.62 in. (396 mm) |
Woofer Displacement | 0.339 cu. ft. (9.6 Liters) |
Sealed Box Volume (Vb) | — |
Shipping Weight | 106.30 Lbs. (48.2 Kg.) |
Vented Box Volume (Vb) | 8.0 cu. ft. (226.5 Liters) |
