KW-Z900W
Monitor
- High Definition Monitor
- Yes
- Screen Size
- 9″ HD Screen
- Touch Panel
- Capacitive
- Touch Panel Surface
- Anti Finger Print, Anti Glare
- Key Illumination Color
- Blue
- Dimmer
- Yes
- Multilingual Display
- Yes (English / Spanish / French)
Media Playback
- MP3 Compatible with Tag
- USB
- WMA Compatible with Tag
- USB
- WAV Compatible with Tag
- USB
- AAC Compatible with Tag
- USB
- FLAC Compatible with Tag
- USB
- H.264 Compatible
- USB
- WMV Compatible
- USB
- MPEG 1/2 Compatible
- USB
- MPEG 4 Compatible
- USB
- MKV Compatible
- USB
Bluetooth Control
- Built-in Bluetooth[1]
- Yes (Version 5.3, Wired-Mic included)
- Hands Free Call
- Yes (HFP1.6)
- 2 Phones Full-Time Connection
- Yes
- Audio Streaming & Control (A2DP, AVRCP)
- Yes
- Supported Audio Formats
- AAC / SBC
- Voice Dialing (voice recognition compatible mobile phone required)
- Yes
- Phone Book Access Profile (PBAP)
- Yes
Wi-Fi Control
- Built-in Wi-Fi
- Yes
Android Control
- Android Auto[2]
- Yes (via Wi-Fi or USB)
- Mirroring for Android
- Yes (via Wi-Fi or USB)
iPod/iPhone Control
- Apple CarPlay[3]
- Yes (via Wi-Fi or USB)
- Mirroring for iPhone
- Yes (via Wi-Fi or USB)
USB
- USB Port
- x 1 Type-A (USB2.0 High Speed)
- Position
- Rear
- USB Power Supply
- 2.1A (BC1.2)
Radio Tuner
- SiriusXM Ready
- Yes
- Radio Broadcast Data System (RBDS)
- Yes
- Preset Stations
- 20(FM:15ch, AM:5ch)
- Auto Memory Entry
- Yes
- FM
- Frequency Range
- 87.9 – 107.9MHz
- AM
- Frequency Range
- 530-1,700kHz
Audio
- Maximum Power Output (Front & Rear)
- 50Wx4
- Full Bandwidth Power (Front & Rear)
- 22W x 4 (at less than 10% THD)
- EQ
- Yes (13-Band Graphic EQ)
- Preset EQ
- Yes (7Preset + 1User)
- Bass Boost
- Yes
- High-Pass Filter/Low-Pass Filter
- Yes/Yes
- 3-Way X’over
- Yes
- Time Alignment
- Yes
Inputs and Outputs
- AV Input
- mini jack (AV-IN or Camera-IN switchable) x 1
- Video Out
- RCA x1
- HDMI Terminal
- Yes
- HD Camera Input
- Yes (Only for Rear Camera In)
- Rear view camera Input
- Yes
- Line Output Terminals
- 3 Pairs (Front + Rear + Subwoofer)
- Pre-output Level/Impedance
- 3V
- Subwoofer Output with Level/Frequency Control
- Yes
General
- iDatalink Maestro Ready
- Yes (RR, RR2)
- Wireless Remote Control
- Optional (RM-RK259)
- Steering Remote Control Ready
- Yes
- Dimensions (W x H x D)
- Chassis
- 7″ x 1-15/16″ x 4-3/4″ (178 x 50 x 120 mm)
- Monitor
- 9-7/16″ x 5-1/2″ x 1-1/4″ (240 x 140 x 31 mm)
- Weight
- Chassis
- 2.1 lbs (0.94kg)
- Monitor
- 1.5lbs (0.66kg)
- Unit weight in individual package
- 5.38lbs (2.44kg)
[1]Available functions depend on mobile phone.
[2]Compatible Android phone and compatible active data plan required.
[3][iPhone] SE(2nd G), SE(3rd G), Xs, Xs Max, Xr, 11, 11Pro, 11Pro Max, 12, 12mini, 12 Pro, 12 Pro Max, 13, 13 mini, 13 Pro, 13 Pro Max, 14, 14 plus, 14 Pro, 14 Pro Max, 15, 15Plus, 15Pro, 15ProMax *The service may not be available in certain countries.
