KW-Z1000W
Monitor
- High Definition Monitor
- Yes
- Screen Size
- 10.1″W HD Screen
- Touch Panel
- Capacitive / Bonding
- Gesture Touch Control
- Yes
- Key Illumination Color
- Variable
- Dimmer
- Yes
- Multilingual Display
- Yes[4]
- Live Wallpaper
- Yes
Media Playback
- MP3 Compatible with Tag
- USB
- WMA Compatible with Tag
- USB
- WAV Compatible with Tag
- USB
- AAC Compatible with Tag
- USB
- FLAC Compatible with Tag
- USB( Up to192kHz/24bit )
- DSD Compatible with Tag
- USB
- H.264 Compatible
- USB
- WMV Compatible
- USB
- MPEG 1/2 Compatible
- USB
- MPEG 4 Compatible
- USB
- AVI/MKV Compatible
- USB
Bluetooth Control
- Built-in Bluetooth[1]
- Yes (Version 5.0, Wired-Mic included)
- Hands Free Call
- Yes (HFP1.7)
- 2 Phones Full-Time Connection
- Yes
- Audio Streaming & Control (A2DP, AVRCP)
- Yes
- Supported Audio Formats
- LDAC / AAC / SBC
- 5 BT-Audio Connection
- Yes
- Voice Dialing (voice recognition compatible mobile phone required)
- Yes
- Phone Book Access Profile (PBAP)
- Yes
- Alphabetical Search for Phone Book
- Yes
Wi-Fi Control
- Built-in Wi-Fi
- Yes
Android Control
- Android Auto[2]
- Yes (via Wi-Fi or USB)
- Mirroring for Android
- Yes (via Wi-Fi or HDMI)
iPod/iPhone Control
- CarPlay[3]
- Yes (via Wi-Fi or USB)
- Mirroring for iPhone
- Yes (via HDMI)
USB
- USB Port
- x 2 (High Speed)
- Position
- Rear
- USB Power Supply
- Yes (1.5A High Current Charging)
Radio Tuner
- SiriusXM Ready
- Yes *SiriusXM 360L Ready
- Radio Broadcast Data System (RBDS)
- Yes
- Preset Stations
- 20(FM:15ch, AM:5ch)
- Auto Memory Entry
- Yes
- FM
- Frequency Range
- 87.9 – 107.9MHz
- AM
- Frequency Range
- 530-1,700kHz
Audio
- Maximum Power Output (Front & Rear)
- 50Wx4
- Full Bandwidth Power (Front & Rear)
- 22W x 4 (Full Bandwidth Power, at less than 1% THD)
- EQ
- Yes (13-Band Graphic EQ)
- Preset EQ
- Yes (8Preset + 4user)
- Bass Boost
- Yes
- High-Pass Filter/Low-Pass Filter
- Yes/Yes
- 3-Way X’over
- Yes
- High-Resolution Audio
- Yes
- K2 Technology
- Yes
- Space Enhancement
- Yes
- Sound Response
- Yes
- Sound Lift
- Yes
- Volume Link EQ
- Yes
- Time Alignment
- Yes
- Dual-Zone Function
- Yes
Inputs and Outputs
- AV Input
- mini jack + RCA Video(AV-IN or CAM4 switchable)
- Video Out
- RCA
- HDMI Terminal
- Yes
- Rear view camera Input
- Yes
- Front view camera Input
- Yes
- 3rd Camera Input
- Yes
- Line Output Terminals
- 3 Pairs (Front + Rear + Subwoofer)
- Pre-output Level/Impedance
- 5.0V / 10k ohms
- Subwoofer Output with Level/Frequency Control
- Yes
General
- iDatalink Maestro Ready
- Yes
- JVC Portal App
- Yes
- Remote Control Application
- Yes
- Face Type
- Viewing Angle Adjustment
- Yes (0 – 20 degree, default : 0 degree) 4 steps
- Wireless Remote Control
- Ready (RM-RK258 required)
- Steering Remote Control Ready
- Yes
- Learning Direct OEM Remote
- Yes
- Dimensions (W x H x D) / Weight
- Installation Size
- 7″ x 3-15/16″ x 6-2/16″ (178 x 100 x 155 mm)
- Weight
- 7.28 lbs. (3.25kg)
