Product Highlights
- Type: Mono subwoofer amplifier
- Power Output:
- 330 watts RMS x 1 at 4 ohms
- 600 watts RMS x 1 at 2 ohms
- 600 watts RMS x 1 at 1 ohm
- Frequency Response: 10-400 Hz
- Class: Class D
- Dimensions: 8.66″W x 2.21″H x 8.3″D
- Featured in “Best subwoofer amplifiers for 2025”
Key Features
- Efficient Power Output:
- Class D amplifier design for optimal efficiency
- 600 watts RMS at 2 ohms or 1 ohm
- Low minimum impedance (1 ohm) for flexible subwoofer configurations
- Bass Enhancement Controls:
- Variable low-pass filter (50-400 Hz, 24 dB/octave)
- Variable bass boost (0-12 dB at 50 Hz)
- Optional RUX-KNOB.2 remote bass level control
- Versatile Input Options:
- Accepts both preamp and speaker-level inputs
- Speaker-level inputs handle up to 10V
- Multiple turn-on options (Remote, DC offset)
- Signal-sensing automatic turn-on with speaker-level inputs
- Installation Flexibility:
- Preamp outputs for daisy-chaining additional amplifiers
- CTA-2006 compliant for accurate power ratings
- Compact chassis fits in tight installation spaces
Package Contents
- Mono subwoofer amplifier
- Two 30A ATO fuses (installed)
- 2 End caps
- Four 3/4″ screws
- Four 1/4″ screws
- 2mm Allen key
- Owner’s manual
- Alpine Verification Certificate
- Power supply note
- Online product registration information
